LPG Liquid 100hp IMPCO Model J Regulator Fuel System Parts

  • 1
  • 2
  • 3

Brand Name : IMPCO

Model Number : MODEL J Regulator

Certification : UL

Place of Origin : USA

MOQ : 24

Payment Terms : T/T

Supply Ability : 1200pcs per 8weeks

Delivery Time : 8 weeks

Packaging Details : carton

Price : Depending on quantity

Material : Aluminum

Fuel Type : LPG Liquid/Vapor

Operating Temperature Range : .-40°F to +250°F (-40°C to +121°C)

HP/KW Rating : 100 hp (74.6 kW)

Applications. : Mobile, stationary, industrial and automotive

Inlet Pressure : Maximum 312 psi (21.51 Bar); Minimum 30 psi (207 kPa)

Mounting Position : Vertical

Diaphragm Material : Silicone and Fluorosilicone

Contact Now

Model J Regulator / Vaporizer , Two Vapor Outlet Pressures Available
Model J
DESCRIPTION
The Model J regulator/vaporizer delivers reliable performance and pressure output consistency. Its reliability, especially with questionable fuel quality, has made it an industry standard for many years.
Two vapor outlet pressures are available. The standard JB blue provides -1.5” w.c. (-0.37 kPa). The optional JO provides -0.5” w.c. (-0.12 kPa). The port size and mounting pad locations are identical to the Cobra regulator and include a primary pressure test port and “left” or “right” fuel outlets.
SPECIFICATIONS
Fuel Type LPG Liquid/Vapor
Inlet Pressure
Maximum 312 psi (21.51 Bar)
Minimum 30 psi (207 kPa)
Outlet Pressure (Nominal) 　
JB (blue spring) -1.5” w.c. (-0.37 kPa
JO (orange spring) -0.5” w.c. (-0.12 kPa)
HP/kW Rating 100 hp (74.6 kW)
Operating Temperature Range -40°F to +250°F (-40°C to +121°C)
Fuel Filtration Required 40 micron
Heating Chamber Source Required for LPG Liquid
Mounting Position Vertical recommended. Horizontal position can be used when fuel contamination can be controlled with HD-5 or HD-10 specified LPG fuel.
Applications Mobile, stationary, industrial and automotive
Certification UL (AU1502), Inquire for specific ECE approval

LPG Liquid 100hp IMPCO Model J Regulator Fuel System Parts
LPG Liquid 100hp IMPCO Model J Regulator Fuel System PartsLPG Liquid 100hp IMPCO Model J Regulator Fuel System PartsLPG Liquid 100hp IMPCO Model J Regulator Fuel System Parts
